QuartzGrip® Phenolic Grating

QuartzGrip® Phenolic Grating

QuartzGrip Logo
  • ANTI-SLIP
  • FIRE RESISTANT
  • LOW SMOKE & TOXINS

Phenolic grating offers maximum fire resistance, low smoke and low toxic fume emissions and low char yield making it the number one choice in sites at high risk of fire or in enclosed spaces such as tunnels where fumes can build up.

Read full description

Description

Phenolic grating is manufactured using phenolic resin and offers maximum fire resistance, low smoke and low toxic fume emissions and low char yield making it the number one choice in sites at high risk of fire or in enclosed spaces such as tunnels where fumes can build up. Non-flammability enables it to withstand direct flame for an extended period without sustaining major structural damage. It’s most commonly used for high risk working areas such as oil rigs, underground tunnels, subways, refineries, ship decks and ship lifeboat access gangways. As with all GRP products, it’s lightweight and requires zero maintenance making it an ideal solution for hard-to-reach locations and the gritted surface reduces the risk of slips, trips and falls even in wet, icy or oily conditions.

Phenolic Grating has 12 to 14 week lead time. We can also provide Phenolic Profiles.  If you would like us to quote or need more information, contact us here.

Height  50mm
Load Bar Centre   50mm
Load Bar Width   50mm
% Free Space   50%
Cross Bar Spacing   150mm
Weight  17kg per square metre

Property Index Standard
Fire Retardance Flame spread index < 10 ASTM-E84
Fire Resistance Burn for 1 hr @ 927°C ASTM-E119
Load USCG test = load > 500kg/m2 applied after burn at 927°C for 1 hr ASTM-E119
Burn Rate Burn rate = 0 ASTM-D-635
Load Normal operating temperature -100 to +180°C
